$27.91
Add to Cart
Seagate 1280MB (1.2GB) IDE Hard Drive, TESTED GOOD, ST31276A
Appearance: Used
Functionality: Working
Description:
============
Similar to pictured, a Seagate ST31276A IDE Hard Drive - tested good. Manual is available at: http://www.seagate.com/staticfiles/support/disc/iguides/ata/lapazig2.pdf.
Warranty and Returns:
=====================
We understand that there may be compatibility issues, space constraints, or it just doesn’t look perfect. This item can be returned within 14-days for ANY reason. However, shipping to and from is not refundable.
Shipping:
=========
- Other shipping methods are available – contact us for details.
- Combined shipping is available for most items – contact us for details.
- Local pickup is also available at no cost.
About Us:
=========
The Computer Preservation Group is dedicated to the preservation of historical computers. To help fund ongoing operations, select items are made available. To learn more, please visit our website: www.computerpreservation.com. Thank you for your support!
Stock#:J1276.GG#1.66
Details from ftp://ftp.seagate.com/techsuppt/at/st31276a.txt:
Medalist 1276 AT (Lapaz CFS1276A)
FORMATTED CAPACITY _______________________1280.95
ACTUATOR TYPE ____________________________VOICE COIL
CYLINDERS __PHYSICAL______________________4893
HEADS ______PHYSICAL______________________4
DISCS (3.5 in) ___________________________2
MEDIA TYPE _______________________________THIN FILM
HEAD TYPE ________________________________THIN FILM
RECORDING METHOD _________________________ZBR RLL (1,7)
INTERNAL TRANSFER RATE (Mbits/sec) _______33.6 to 67.2
EXTERNAL TRANSFER RATE (Mbytes/sec) ______up to 16.6
PIO MODE _________________________________4
DMA SUPPORT ______________________________EISA Type B
SPINDLE SPEED (RPM) ______________________4500
AVERAGE LATENCY (mSEC) ___________________6.67
BUFFER ___________________________________64K
Read/Write Multiple, Read Look-Ahead,
Multi-Segmented
INTERFACE ________________________________ATA
SECTORS PER DRIVE (LBA mode) _____________2,501,856
TPI (TRACKS PER INCH) ____________________4973
BPI (KBITS PER INCH) _____________________88.4
AVERAGE ACCESS (ms) ______________________12.5
SINGLE TRACK SEEK (ms) ___________________3
MAX FULL SEEK (ms) _______________________24
MTBF (power-on hours) Office _____________300,000
SHOCK (G's):
operating (Read/Write) __________5
abnormal ________________________
nonoperating ____________________75
ACOUSTICS (bels) (typ/max) _______________38/
POWER DISSIPATION (watts) ________________
POWER REQUIREMENTS: +12V START-UP (amps) _1.2
POWER MANAGEMENT (Watts):
ACTIVE _______________4.6
IDLE _________________3.5
STANDBY ______________1.0
WRITE PRECOMP (cyl) ______________________N/A
REDUCED WRITE CURRENT (cyl) ______________N/A
LANDING ZONE (cyl) _______________________AUTO
IBM AT DRIVE TYPE ________________________*
Physical:
Height (inches/mm): 1.00/25.4
Width (inches/mm): 4.00/101.6
Depth (inches/mm): 5.75/146.1
Weight (lbs/kg): 1.3/0.59
Functionality: Working
Description:
============
Similar to pictured, a Seagate ST31276A IDE Hard Drive - tested good. Manual is available at: http://www.seagate.com/staticfiles/support/disc/iguides/ata/lapazig2.pdf.
Warranty and Returns:
=====================
We understand that there may be compatibility issues, space constraints, or it just doesn’t look perfect. This item can be returned within 14-days for ANY reason. However, shipping to and from is not refundable.
Shipping:
=========
- Other shipping methods are available – contact us for details.
- Combined shipping is available for most items – contact us for details.
- Local pickup is also available at no cost.
About Us:
=========
The Computer Preservation Group is dedicated to the preservation of historical computers. To help fund ongoing operations, select items are made available. To learn more, please visit our website: www.computerpreservation.com. Thank you for your support!
Stock#:J1276.GG#1.66
Details from ftp://ftp.seagate.com/techsuppt/at/st31276a.txt:
Medalist 1276 AT (Lapaz CFS1276A)
FORMATTED CAPACITY _______________________1280.95
ACTUATOR TYPE ____________________________VOICE COIL
CYLINDERS __PHYSICAL______________________4893
HEADS ______PHYSICAL______________________4
DISCS (3.5 in) ___________________________2
MEDIA TYPE _______________________________THIN FILM
HEAD TYPE ________________________________THIN FILM
RECORDING METHOD _________________________ZBR RLL (1,7)
INTERNAL TRANSFER RATE (Mbits/sec) _______33.6 to 67.2
EXTERNAL TRANSFER RATE (Mbytes/sec) ______up to 16.6
PIO MODE _________________________________4
DMA SUPPORT ______________________________EISA Type B
SPINDLE SPEED (RPM) ______________________4500
AVERAGE LATENCY (mSEC) ___________________6.67
BUFFER ___________________________________64K
Read/Write Multiple, Read Look-Ahead,
Multi-Segmented
INTERFACE ________________________________ATA
SECTORS PER DRIVE (LBA mode) _____________2,501,856
TPI (TRACKS PER INCH) ____________________4973
BPI (KBITS PER INCH) _____________________88.4
AVERAGE ACCESS (ms) ______________________12.5
SINGLE TRACK SEEK (ms) ___________________3
MAX FULL SEEK (ms) _______________________24
MTBF (power-on hours) Office _____________300,000
SHOCK (G's):
operating (Read/Write) __________5
abnormal ________________________
nonoperating ____________________75
ACOUSTICS (bels) (typ/max) _______________38/
POWER DISSIPATION (watts) ________________
POWER REQUIREMENTS: +12V START-UP (amps) _1.2
POWER MANAGEMENT (Watts):
ACTIVE _______________4.6
IDLE _________________3.5
STANDBY ______________1.0
WRITE PRECOMP (cyl) ______________________N/A
REDUCED WRITE CURRENT (cyl) ______________N/A
LANDING ZONE (cyl) _______________________AUTO
IBM AT DRIVE TYPE ________________________*
Physical:
Height (inches/mm): 1.00/25.4
Width (inches/mm): 4.00/101.6
Depth (inches/mm): 5.75/146.1
Weight (lbs/kg): 1.3/0.59
